Graco GX-16 - Page 27

Parts
313536U 27
Ref. Part Description
Quantity
24K233 24K234
401 257514
DISPENSER, GX-16, 24:1, pre-assy
1 1
402 122714
O-RING, fluoroelastomer, #904, 75a
2 2
403 122707
O-RING, fluoroelastomer, #904, 75a
3 3
404 122720
ADAPTER, jic06xsae04, mm, ms, 6k, fluoroelastomer
1 1
405 122717
ADAPTER, swivel, jic06xsae04, fm, ms, 6k
1 1
406 122710
ADAPTER, jic05xsae04, mm, ss, 6k
1 1
407 122709
ADAPTER, swivel, jic05xsae04, fm, ss, 6k
1 1
408 129342
FITTING, elbow, swivel, 90, jic06, fm, ss
2 2
409 122715
FITTING, elbow, swivel, 90, jic05, fm, ss
2 2
410 122713
SWITCH, proximity
1 1
411 15Y177
FITTING, 7/16 org x 7/16 jic ext
1 1
412 122718
FITTING, elbow, swivel, 90, jic04, fm, ms
2 2
413 122711
FITTING, elbow, 90, jic04xsae04
1 1
414 257701
RESTRICTOR, orifice assy, 0.011
1
415 257724
RESTRICTOR, orifice assy, 0.061
1
