Graco Husky 1040 - Air Motor Parts List Details; Standard Air Motor Parts; Remote Air Motor Parts; SST Air Motor Parts

308443 29
Parts
Air Motor Parts List (Matrix Column 2) Air Motor Parts List (Matrix Column 2)
Digit
Ref.
No. Part No. Description Qty
7 1 188838 HOUSING, center;
aluminum
1
2 188854 COVER, air valve;
aluminum
1
3 116344 SCREW, mach, hex flange
hd; M5 x 0.8; 12 mm (0.47
in.)
9
4
† 188618 GASKET, cover; foam 1
5 188855 CARRIAGE; aluminum 1
6
† 108730 O-RING; nitrile 1
7
† 188616 BLOCK, air valve; acetal 1
8 188615 PLATE, air valve; sst 1
9
† 188617 SEAL, valve plate; buna-N 1
10
† 112181 PACKING, u-cup; nitrile 2
11 188612 PISTON, actuator; acetal 2
12 188613 BEARING, piston; acetal 2
13
‡ 104765 PLUG, pipe; headless 2
14
‡ 115671 FITTING, connector; male 2
15 188611 BEARING, pin; acetal 2
16 188610 PIN, pilot; stainless steel 2
17
† 157628 O-RING; buna-N 2
18
† 188614 BLOCK, pilot; acetal 1
19 188609 BEARING, shaft; acetal 2
20 116343 SCREW, grounding 1
22 188603 GASKET, air cover; foam 2
23 188839 COVER, air; aluminum 2
24 188608 SHAFT, diaphragm; sst 1
25 115643 SCREW; M8 x 1.25; 25 mm
(1 in.)
12
Digit
Ref.
No. Part No. Description Qty
8 Same as 7 with the following exceptions
1 195921 HOUSING, center;
remote, aluminum
1
23 195917 COVER, air; remote 2
R Same as 7 with the following exceptions
1 15K009 HOUSING, center;
stainless steel
1
2 15A735 COVER, air valve;
stainless steel
1
8
 15H178 PLATE, air valve;
stainless steel
1
9- - -
23 15A736 COVER, air; stainless
steel
2
S 1 15K009 HOUSING, center;
stainless steel
1
2 15A735 COVER, air valve;
stainless steel
1
8
 15H178 PLATE, air valve;
stainless steel
1
9- - -
23 15B794 COVER, air; remote,
stainless steel
2
