Graco Husky 1040 - Fluid Section Parts List Details; Acetal;PVDF Fluid Section Parts; Polypropylene Fluid Section Parts

30 308443
Fluid Section Parts List (Matrix Column 3) Fluid Section Parts List (Matrix Column 3)
Digit
Ref.
No. Part No. Description Qty.
1 101 189377 COVER, fluid; acetal 2
102 189371 MANIFOLD, inlet; acetal 1
103 189374 MANIFOLD, outlet; acetal 1
104 188607 PLATE, air side; alum. 2
105 189380 PLATE, fluid side; acetal 2
106 112560 SCREW; M8 x 1.25; 70
mm (2.76 in.); sst
12
110▲ 188621 LABEL, warning 1
111 112182 MUFFLER 1
112 112559 SCREW; M8 x 1.25; 40
mm (1.57 in.); sst
12
113 193282 CAP, bolt; SST 8
2 101 189376 COVER, fluid;
polypropylene
2
102 189370 MANIFOLD, inlet;
polypropylene
1
103 189373 MANIFOLD, outlet;
polypropylene
1
104 188607 PLATE, air side; alum. 2
105 189379 PLATE, fluid side;
polypropylene
2
106 112560 SCREW; M8 x 1.25; 70
mm (2.76 in.); sst
12
110▲ 188621 LABEL, warning 1
111 112182 MUFFLER 1
112 112559 SCREW; M8 x 1.25; 40
mm (1.57 in.); sst
12
113 193282 CAP, bolt; SST 8
Digit
Ref.
No. Part No. Description Qty.
5 101 189378 COVER, fluid; PVDF 2
102 189372 MANIFOLD, inlet; PVDF 1
103 189375 MANIFOLD, outlet; PVDF 1
104 188607 PLATE, air side; alum. 2
105 189381 PLATE, fluid side; PVDF 2
106 112560 SCREW; M8 x 1.25; 70
mm (2.76 in.); sst
12
110▲ 188621 LABEL, warning 1
111 112182 MUFFLER 1
112 112559 SCREW; M8 x 1.25; 40
mm (1.57 in.); sst
12
113 193282 CAP, bolt; SST 8
