Graco Husky 2150e - Compressor Wiring

Installation
Compressor Compressor
Compressor
Wiring Wiring
Wiring
Toavoidinjuryfrom󰘰re,explosion,orelectric
shock,allelectricalwiringmustbedonebya
quali󰘰edelectricianandcomplywithalllocalcodes
andregulations.
FollowtheseinstructionstowireGracoCompressor
24Y544(120V)or24Y545(240V).
NOTE: NOTE:
NOTE:
Useonlycopperwirewithaninsulationrating
of75°Corhigher.
1.Removethecoverfromthecompressor’s
electricalbox.
2.Installwiringsystemwithproperconnections(i.e.
conduit/󰘰ttings,powercable/cablegrip)tothe
compressorelectricalbox.
3.Connectlinepower(120VACor240VAC,
dependingonyourcompressor)toL1andL2/N.
Connectsupplygroundto
.Useminimum
12AWG(4mm
2
)wirewhenthesystemis
con󰘰guredfora16Acircuitand14AWG(2.5
mm
2
)whencon󰘰guredfora12Acircuit.Torque
terminalsto10in-lb(1.2N•m).
4.Reinstallthecoveroftheelectricalbox.Torque
screwsto60in-lb(6.8N•m).
Figure10
L1
L2
A
KEY KEY
KEY
A A
A
Topowersupply
183A4068H
