Storage
22 312001B
Unfolding the Sprayer
1. If folded for compact,
shelf storage, unfold
handle (a) and align as
shown.
2. Tighten wingnuts (b).
3. Remove suction tube
from hook (c) in the back of
the sprayer.
4. Grasp cart handle
securely with one hand.
With the other hand lift
and pull Fold-n-Store
handle (a) located in front
of sprayer frame, toward
you. Lift up front of sprayer
until you hear a click and
the cart is locked in place.
Storage Options
• The folded sprayer can be
stored on a wall as shown.
• For compact, shelf
storage, loosen, but do
not remove, wingnuts
(c) and fold handle
down as shown.
a
b
ti9675
c
ti9430a
ti9431a
ti9677a
c
ti9676a
