Storage
312001B 21
Stowing Sprayer
1. Screw inlet screen onto
suction tube.
2. Coil hose. Leave it
connected to sprayer. Wrap
hose around hose wrap
bracket.
3. Secure a plastic bag around
suction tube to catch any drips.
4. Store sprayer indoors.
Fold-n-Store Storage
The sprayer cart can be folded for convenient and com-
pact storage.
Folding the Sprayer
1. Grasp cart handle
securely with one hand.
With the other hand, lift
and pull Fold-n-Store han-
dle (a) in front of sprayer
frame, toward you.
2. Push front of sprayer
down, toward floor while
holding cart handle
securely with your other
hand as shown.
3. Slide suction tube under
hook (b) in back of
sprayer cart.
CAUTION
• Before storing sprayer make sure all water is
drained out of sprayer and hoses.
• Do not allow water to freeze in sprayer or hose.
• Do not store sprayer under pressure.
ti9433a
ti9366a
WLD
a
ti9425a
ti9432a
b
ti9428a
