Graco Magnum ProX7 User Manual

Component Identification
6 312001B
Component Identification
A Airless spray gun Dispenses fluid.
B Power switch Turns sprayer ON and OFF.
C Pressure control knob Increases (clockwise) and decreases (counter-clockwise) fluid pressure
in pump, hose, and spray gun.
C1 Setting Indicator To select function, align symbol on pressure control knob with setting
indicator, page 8.
D Pump fluid outlet fitting Threaded connection for paint hose.
E
InstaClean
™
fluid filter
• Filters fluid coming out of pump to reduce tip plugging and improve
finish.
• Self cleans only during pressure relief.
F
ProX Power-Piston
™
Pump (behind Easy
Access door, not shown)
Pumps and pressurizes fluid and delivers it to paint hose.
F1 Easy Access door Easy Access door permits quick access to outlet valve. To remove door,
insert flat blade of screwdriver into slot on the bottom of the door (as
shown on page, 7).
G suction tube Draws fluid from paint pail into pump.
H Prime tube (with diffuser) Drains fluid in system during priming and pressure relief.
J Prime/Spray valve • In PRIME position (pointing down) directs fluid to prime tube.
• In SPRAY position (pointing forward) directs pressurized fluid to paint
hose.
• Automatically relieves system pressure in overpressure situations.
K Storage compartment Provides onboard storage for spray tips and/or tools.
L Inlet screen Prevents debris from entering pump.
M Paint hose Transports high-pressure fluid from pump to spray gun.
N
Fold-n-Store
™
Handle
Used to fold cart frame for hanging on wall.
P Practice Spray Board Instructs user on how to perform basic spraying techniques and provides
surface to practice techniques prior to spraying surfaces.
Q Tip guard Reduces risk of fluid injection injury.
R Reversible spray tip • Atomizes fluid being sprayed, forms spray pattern and controls fluid
flow according to hole size.
• Reverse unclogs plugged tips without disassembly.
S Gun trigger safety lever (page 8) Prevents accidental triggering of spray gun.
T Gun fluid inlet fitting Threaded connection for paint hose.
U Power Flush attachment Connects garden hose to suction tube for power flushing water-base
fluids.
V Gun fluid filter Filters fluid entering spray gun to reduce tip clogs.
W Hose wrap bracket Stows paint hose.
X Pail hanger For transporting pail by its handle.
Y
SpillGuard
™
tray
Protective tray to set sprayer and paint pail on during operation.
Z Sample spray shield Introduces benefits of a spray shield. Blocks paint from surfaces you do
not want to spray.
AA
QuickAccess
™
Inlet
Permits quick access to inlet valve to clear debris (ProX9 only).
