Parts
38 312394ZAC
† Not shown. See Integrated Heat manual referenced at beginning of this manual.
▲ Replacement Danger and Warning labels, tags, and cards are available at no cost.
Ref Part Description Qty
301 --- Refer to Tanks for Use with Dust Covers and
Tanks for Use with Clampdown Covers, page
44, for replacement or spare parts.
1
302 LC0861 BLANKET, heat, 7.5L tank, 220V 1
303 256558 SWITCH, assy, thermal, 125C, 3P, M8 1
304 LC0056 BLANKET, insulation 1
304a
121208
LABEL, hot surface
305 256611 SENSOR, assy, 1.5 in. rtd, 4-pin M8 1
306 121615 HARNESS, splitter, M8, 4-pin, female/male, 3 m 1
307 121478 FITTING, compression, 3/16 x 1/4 npt 1
308 256612 SENSOR, assy, 4.25 in. rtd, 4-pin M8 1
309 121682 CABLE, M8, 3-pin, male / female, 3 meter,
molded
1
310 † 121633 CIRCUIT, breaker, 2-pole, 4A, C type 1
