Graco ProBell Instructions And Parts

Troubleshooting
Code
Event
Type
Name Description
Solution
P611 or
P612
Alarm
Sensor
Disconnected,
Inner Shaping
Air
The returned value of the
pressure sensor for inner
shaping air is zero
P6Y1 or
P6Y2
Alarm
Sensor
Disconnected,
Outer Shaping
Air.
The returned value of the
pressure sensor for outer
shaping air is zero.
• Replace cable 17K902.
• Replace volltage to pressure regulator
Table 5 Solenoid Errors
Code
Event
Type
Name Description Remedy
WJ31
or
WJ32
Alarm
Paint Solenoid
Removed
System does not detect the
Paint Trigger solenoid.
Electronic: Verify wiring on terminals 1
and 3. Manual: Verify wiring on terminals
1 and 2.
WJ41
or
WJ42
Alarm Dump
Solenoid
Removed
System does not detect the
Dump Trigger solenoid.
Electronic: Verify wiring on terminals 4
and 5. Manual: Verify wiring on terminals
5 and 6.
WJ51
or
WJ52
Alarm
Cup Wash
Solenoid
Removed
System does not detect the
CupWashsolenoid.
Electronic: Verify wiring on terminals 6
and 7. Manual: Verify wiring on terminals
7 and 8.
WJ61
or
WJ62
Alarm
Inner Shaping
Air Solenoid
Removed
System does not detect
the Shaping Air 1 (inner)
solenoid.
Electronic: Verify wiring on terminals
13 and 14. Manual: Verify wiring on
terminals 17 and 18.
WJ71
or
WJ72
Alarm
Outer Shaping
Air Solenoid
Removed
System does not detect
the Shaping Air 2 (outer)
solenoid.
Electronic: Verify wiring on terminals
20 and 21. Manual: Verify wiring on
terminals 20 and 21.
WJ81
or
WJ82
Alarm Turbine Air
Solenoid
Removed
System does not detect
the Turbine Air solenoid,
Manual Air Controller.
Manual: Verify wiring on terminals 3 and
4 in the Manual Air Controller.
WJ91
or
WJ92
Alarm Auxiliary 1
Solenoid
Removed
System does not detect the
Auxiliary 1 solenoid.
Electronic: Verify wiring on terminals
27and 28. Manual: Verify wiring on
terminals 23 and 24.
WJA1
or
WJa2
Alarm Auxiliary 2
Solenoid
Removed
System does not detect the
Auxiliary 2 solenoid.
Electronic: Verify wiring on terminals
29 and 30. Manual: Verify wiring on
terminals 25 and 26.
WJB1
or
WJB2
Alarm Auxiliary 3
Solenoid
Removed
System does not detect the
Auxiliary 3 solenoid.
Electronic: Verify wiring on terminals
31 and 32. Manual: Verify wiring on
terminals 27 and 28.
Table 6 Bearing Air Pressure Errors (Manual Air Controller Only)
Code
Event
Type
Name Description
Solution
P9P1
or
P9P2
Alarm
Air Control
Pressure Low
Air Controller no longer
detects bearing air.
(Manual air controller
only.)
Verify that inlet air pressure and flow are
sufficient.
20 3A3954B
