Graco ProBell Instructions And Parts

Component Ident
ification
Component Ide
ntification
Electronic Ai
r Controller
Ref. Compo
nent
A
Contr
ol Module — manages the operation
of al
l air controller components
BTerm
inal Blocks —provide electrical wire
conn
ections
C Solenoid Valves — send air activation
signals for paint, dump, and solvent valves;
auxiliary signals available for system
flexibility
D
Air Manifold — directs incoming air to the
controller components
E
In
ner Shaping Air Solenoid Valve — shuts
of
f the flow of the inner shaping air
Ref. Compo
nent
F
Outer
Shaping Air Solenoid Valve — shuts
off t
he flow of the outer shaping air
G
Volt
age to Pressure Regulator — converts
volt
age to pressure for the inner shaping air
HVolt
age to Pressure Regulator — converts
volt
age to pressure for the outer shaping air
J
Optocoupler — isolated input to trigger
paint valve from PLC
3A3954B
7
