System Connections and Fe ature s
System Connec
tions and Features
Air Line Port Label
Speed Controller
Connections
Electronic
Air Controller
Connections
Manual Air
Controller
Connections
B(BearingAi
r)
* *
BK (Braking Air)
BR (Bearing Air Return)
* *
DT (Dump V
alve Trigger)
PT (Paint Valve Trigger)
SI (Shaping Air Inner)
SO (Sha
ping Air Outer)
ST (Solvent Trigger)
TA (Turbine Air)
* *
Aux
iliary Triggers (for system
flex
ibility)
1, 2, 3,
*In
systems with a speed controller, bearing air, bearing air return, and turbine air must be used from the
spe
ed controller, not the manual air controller.
6 3A3954B
