Graco Reactor 2 E-30 Operation

Spraying
Pressure Pressure
Pressure
Relief Relief
Relief
Procedure Procedure
Procedure
FollowthePressureReliefProcedure
wheneveryouseethissymbol.
Thisequipmentstayspressurizeduntil
pressureismanuallyrelieved.Tohelpprevent
seriousinjuryfrompressurizeduid,such
asskininjection,splashinguidandmoving
parts,followthePressureReliefProcedure
whenyoustopsprayingandbeforecleaning,
checking,orservicingequipment.
The Fusion AP gun is shown.
1.Presstostopthepumps.
2.Turnoffallheatzones.
3.Relievepressureingunandperformgun
shutdownprocedure.Seeyourgunmanual.
4.ClosegunuidinletvalvesAandB.
5.Shutofffeedpumpsandagitator,ifused.
6.Routeuidtowastecontainersorsupply
tanks.TurnPRESSURERELIEF/SPRAYvalves
(SA,SB)toPRESSURERELIEF/CIRCULATION
.
Ensuregaugesdropto0.
7.Engagegunpistonsafetylock.
8.Disconnectthegunairlineandremovethe
gunuidmanifold.
62 333023U
