Graco Reactor 2 E-30 Operation

Spraying
Spraying Spraying
Spraying
The Fusion AP gun is shown.
1.Engagegunpistonsafetylockandclosegun
uidinletvalvesAandB.
Fusion Fusion
Fusion
Probler Probler
Probler
2.Attachgunuidmanifold.Connectgunair
line.Openairlinevalve.
3.Adjustthegunairregulatortodesiredgun
airpressure.Donotexceedthemaximum
ratedairpressure.
4.SetPRESSURERELIEF/SPRAYvalves(SA,SB)
toSPRAY
.
5.Verifyheatzonesareonandtemperatures
andpressuresareontarget,see
Homescreen,page39.
6.Openuidinletvalvelocatedateachpump
inlet.
7.Presstostartmotorandpumps.
8.Checkuidpressuregauges(GA,GB)
toensureproperpressurebalance.If
imbalanced,reducepressureofhigher
componentbyslightly slightly
slightly
turningPRESSURE
RELIEF/SPRAYvalveforthatcomponent
towardPRESSURERELIEF/CIRCULATION
untilgaugesshowbalancedpressures.
