Theinletstrainerslteroutparticlesthatcan
plugthepumpinletcheckvalves.Inspectthe
screensdailyaspartofthestartuproutine,and
cleanasrequired.
Isocyanatecancrystallizefrommoisture
contaminationorfromfreezing.Ifthechemicals
usedarecleanandproperstorage,transfer,and
operatingproceduresarefollowed,thereshould
beminimalcontaminationoftheA-sidescreen.
CleantheA-sidescreenonlyduringdaily
startup.Thisminimizesmoisturecontamination
byimmediatelyushingoutanyisocyanate
residueatthestartofdispensingoperations.
1.Closetheuidinletvalveatthepumpinlet
andshutofftheappropriatefeedpump.
Thispreventsmaterialfrombeingpumped
whilecleaningthescreen.
2.Placeacontainerunderthestrainerbaseto
catchdrainoffwhenremovingthestrainer
plug(C).
3.Removethescreen(A)fromthestrainer
manifold.Thoroughlyushthescreenwith
compatiblesolventandshakeitdry.Inspect
thescreen.Nomorethan25%ofthemesh
shouldberestricted.Ifmorethan25%ofthe
meshisblocked,replacethescreen.Inspect
thegasket(B)andreplaceasrequired.
4.Ensurethepipeplug(D)isscrewedintothe
strainerplug(C).Installthestrainerplug
withthescreen(A)ando-ring(B)inplace
andtighten.Donotovertighten.Letthe
gasketmaketheseal.
5.Opentheuidinletvalve,ensurethatthere
arenoleaks,andwipetheequipmentclean.
Proceedwithoperation.
Figure15
333023U 65
