Graco Reactor 2 H-XP2 Repair Parts

ElectricalSchematics
TCM TCM
TCM
Schematic Schematic
Schematic
1
15D906
24U855
CB11 CB12 CB13 CB14 CB15
HOSE
MOTOR A HEAT B HEAT TRANS
17G687 (15kW, 20kW),
24T242 (10 kW)
Overtemperature Switchs
BLKBLK
RED
TB21 / 17B856
TB31
17D780
To TB03
To TB02
10kW - 17G685
15k, 20kW - 17G686
To HCM
To ADM
To Ground Bar
To Ground
Bar
To Heated
Hose
2
24W204
A RTD
B RTD
B HEATER
A HEATER
Transformer Fan
24R756
Hose Transformer
127290
127068
127068
TCM
ti26607B
3
4
To Hose
RTD
1
LocatenearTCM.
2
DirectconnectheaterelementstoTCMfor15kW
and20kWsystems.Harness17G684andspice
connectors(255716)usedfor10kWsystems.
3
TerminalblockTB21onlyusedin15kWand20kW
systems.Usespliceconnectors255716for10kW
systems.
4
Torqueto35–45in.-lb.(4–5N•m).
106 334946H
