Graco Reactor 2 H-XP2 Repair Parts

Shutdown
Shutdown Shutdown
Shutdown
NOTICE NOTICE
NOTICE
Propersystemsetup,startup,andshutdown
proceduresarecriticaltoelectricalequipment
reliability.Thefollowingproceduresensuresteady
voltage.Failuretofollowtheseprocedureswill
causevoltage󰘱uctuationsthatcandamage
electricalequipmentandvoidthewarranty.
1.Presstostopthepumps.
2.Turnoffallheatzones.
3.Relievepressure.See
PressureReliefProcedure,page47.
4.PresstoparktheComponentAand
ComponentBpumps.Theparkoperationis
completewhengreendotgoesout.Verifythe
parkoperationiscompletebeforemovingtonext
step.
5.Presstodeactivatethesystem.
6.Turnofftheaircompressor,airdryer,and
breathingair.
7.TurnthemainpowerswitchOFF.
Topreventelectricshockdonotremoveanycovers
oropentheelectricalenclosuredoorwhilethe
powerisON.
8.Closeall󰘱uidsupplyvalves.
9.SetPRESSURERELIEF/SPRAYvalvesto
SPRAYtosealoutmoisturefromthedrainline.
10.Engagegunpistonsafetylockthenclose󰘱uid
inletvalvesAandB.
Fusion Fusion
Fusion
Probler Probler
Probler
48 334946H
