Graco Reactor 2 H-XP2 Repair Parts

Repair
Replace Replace
Replace
Flow Flow
Flow
Meter Meter
Meter
NOTE: NOTE:
NOTE:
ForH-30,H-40,andH-50Elitemodelsonly.
1.PerformShutdown,page48.
2.PerformPressureReliefProcedure,page47.
3.Disconnectthe󰘱owmetercable.
4.Disconnectthehose.Removethe󰘱owmeter.
5.Installthenew󰘱owmeterandreconnectthe
hose.
Figure6:FlowMeter
6.Connectthe󰘱owmetercable.
7.Enterthek-factoronSystemScreen3on
theADM.RefertoSystem System
System
3 3
3
inyourReactor
operationmanual.
Replace Replace
Replace
Pressure Pressure
Pressure
Transducers Transducers
Transducers
1.Flush.SeeFlushing,page49.
2.SeeShutdown,page48.
3.Disconnecttransducercables(405)from#6and
#7connectorsontheHCM.
4.Removewiretiesconstrainingtransducercable
andremovecablefromcabinet.
5.Installo-ring(406)onnewtransducer(405).
6.Installtransducerinmanifold.Markendofcable
withtape(red=transducerA,blue=transducerB).
7.Routenewcableintocabinetandthreadinto
bundleasbefore.Attachcabletiestobundle
asbefore.
8.ConnectAsidepressuretransducercable
toHCMport#6.ConnectBsidepressure
transducercabletoHCMport#7.
334946H 59
