Graco Reactor 2 H-XP3

Spraying
Enable Enable
Enable
Hose Hose
Hose
Manual Manual
Manual
Mode Mode
Mode
1.EnterSetupModeandnavigatetoSystem
screen3.
2.SettheHoseControlModetoManual.
NOTE: NOTE:
NOTE:
Whenmanualhosemodeisenabled,the
manualhosemodeadvisoryEVCH-Vwillappear.
3.EnterRunModeandnavigatetotheTargets
screen.Usetheupanddownarrowstosetthe
desiredhosecurrent.
Hose Hose
Hose
Current Current
Current
Settings Settings
Settings
Hose Hose
Hose
Current Current
Current
Default
20A
Maximum37A
4.NavigatebacktotheRunModeHomescreen.
Thehosenowdisplaysacurrentinsteadofa
temperature.
NOTE: NOTE:
NOTE:
UntiltheRTDsensorisrepaired,the
T6DHsensorerroralarmwilldisplayeachtime
thesystemispoweredup.
Disable Disable
Disable
Hose Hose
Hose
Manual Manual
Manual
Mode Mode
Mode
1.EnterSetupMode.
2.NavigatetoSystemscreen3.
3.SettheHoseControlModetoFTSorResistance.
56 334945J
