Troubleshooting
16 3A1570L
Troubleshooting
Before performing any troubleshooting procedures:
1. Relieve pressure, page 14.
2. Turn main power OFF .
3. Allow equipment to cool.
Problems
Try the recommended solutions in the order given for
each problem, to avoid unnecessary repairs. Also,
determine that all circuit breakers, switches, and con-
trols are properly set and wiring is correct before assum-
ing there is a problem.
Power
Pumps and Pressures
PROBLEM CAUSE SOLUTION
Heat zones do not operate No power Connect power cord
Turn Main Disconnect Switch ON
Power cord not connected properly Check connections
No power when disconnect switch is
turned on; using 200-240V, 1 phase
or 200-240V, 3 phase power
Power terminal jumper still at
350-415V, 3 phase position, as
shipped from factory
Place jumpers in correct position; see
Operation manual and label inside
front lower cabinet.
External main supply power circuit
breaker trips and Reactor disconnect
switch fails when switch is turned on.
Power terminal jumper was left in
200-240V, 1 phase position. When
using 200-240V, 3 phase or
350-415V, 3 phase power
Place jumpers in correct position; see
Operation manual. Replace main
power disconnect switch; see page
41.
No temperature display lights at
startup
No power Connect power cord
Turn Main Disconnect Switch ON
Control power fuses blown Check and replace fuses on long ter-
minal strip
PROBLEM CAUSE SOLUTION
Pump does not run up and down Motor control valve closed Open air motor shutoff valve
No air supply Air supply line not connected
Open inlet air ball valve
Air pressure regulators set at 0 psi Turn up air pressure regulators
Air motor shuttle valve is centered. Push button on top of air motor shut-
tle valve.
Pump runs but no fluid pressure Fluid inlet ball valves closed Open fluid inlet ball valves
To Next Page
