Graco Reactor A-XP1 Repair Parts

Technical Data
3A1570L 59
Technical Data
*Full load amps with all devices operating at maximum
capabilities with 210 ft (64.1 m) of hose.
***210 ft (64 m) of heated hose will produce the maximum allowable heat capacity. 310 ft (94 m) of heated hose may
be used, but will have 25% less heat capacity.
Category Data
A-25 A-XP1
Maximum Fluid Working Pressure 2000 psi (14 MPa, 138 bar) 3500 psi (24 MPa, 241 bar)
Maximum Air Supply Pressure 125 psi (0.9 MPa, 9 bar) 125 psi (0.9 MPa, 9 bar)
Maximum Air Working Pressure 80 psi (550 kPa, 5.5 bar) 100 psi (689 MPa, 6.9 bar)
Pressure Ratio 25:1 35:1
Air consumption
28 scfm (0.8m
3
/min) 02 tip at
1500 psi install pressure
32 scfm (0.9 m
3
/min) 00 tip at
2000 psi stall pressure
Machine Maximum Power with hose 9000 Watts 13,000 Watts
Voltage Tolerance (50/60 Hz):
200-240VAC Nominal, 1 Phase 195-253VAC
200-240VAC Nominal, 3 Phase (Delta) 195-253VAC
350-415VAC Nominal, 3 Phase
(WYE 200-240VAC Line to Neutral)
338-457VAC
Amperage Requirement (Full Load Peak)* 40 amps @ 230 V, 1 Phase
32 amps @ 230 V, 3 Phase
18.5 amps @ 380 V, 3 Phase
56 amps @ 230 V, 1 Phase
45amps @ 230 V, 3 Phase
26 amps @ 380 V, 3 Phase
Maximum Heater Fluid Temperature 190 °F (88 °C)
Maximum Hose Fluid Temperature 180 °F (82 °C)
Maximum Ambient Temperature 120 °F (49 °C)
Maximum Output 25 lb/min. (11.4 kg/min.) 1.5 gal/min at 2000 psi
Output Per Cycle (A and B) 0.025 gal/cycle (0.095 ltr/cycle) 0.017 gal/cycle (0.094 ltr/cycle)
Heater Power 6000 Watts 10,200 Watts
Hose Power 2790 Watts
Sound Pressure (see NXT air motor manual) 70.2 dB(A)
Sound Power (see NXT air motor manual) 80.1 dB(A)
Viscosity Range 250-1500 centipoise (typical)
Maximum Fluid Inlet Pressure 300 psi (2.1 MPa, 21 bar) or 15% of output pressure
Fluid Inlet/Strainer Filter 20 mesh standard
Air inlet Filter Mesh 40 Micron
Component B (Resin) Inlet 3/4 npt(f) swivel
Component A (Isocyanate) Inlet 3/4 npt(f) swivel
Recirculation/Block Hose Connections Iso (A) side: #5 JIC (m); Resin (B) side: #6 JIC (m)
Maximum Heated Hose Length*** 210 ft of 3/8 ID
Weight 310 lb (140.6 kg)
Wetted Parts Carbon steel, stainless steel, chrome, aluminum,
Fluoroelastomer, PTFE, nylon
