Graco Reactor E-10

Technical Data
72 311075V
Technical Data
Maximum fluid working
pressure
2000 psi (14 MPa, 140 bar)
Electrical requirements Model AP9570, CS9570: 120 Vac, 1 phase, 50/60 Hz, 3500 W;
requires two separate, dedicated 15 A circuits
Model AP9571, CS9571: 240 Vac, 1 phase, 50/60 Hz, 3800 W;
requires two separate, dedicated 10 A circuits
Model AP9572, CS9572: 240 Vac, 1 phase, 50/60 Hz, 3800 W;
requires a single dedicated 16 A circuit
Model 249806, 24R984: 120 Vac, 1 phase, 50/60 Hz, 1800 W;
requires a single dedicated 15 A circuit
Model 249808, 24R985: 240 Vac, 1 phase, 50/60 Hz, 1800 W;
requires a single dedicated
8 A circuit
Generator Size (for Reac-
tor E-10 only)
Heated: 5000 W minimum
Nonheated: 2500 W minimum
Maximum Fluid Tempera-
ture
160°F (71°C)
Maximum Ambient Tem-
perature
110°F (43°C)
Maximum Output 12 lb/min (5.4 kg/min) at 340 cycles/min
Output per Cycle (A and
B)
.00352 gal. (.0133 liter)
Overpressure Relief Recirc/Spray valves automatically relieve excessive fluid pressure
back to supply tanks
Heater Power 120V models: 850 W each; 1700 W total
240V models: 1000 W each; 2000 W total
Sound Pressure 78.7 dB(A) in fast circulation mode
84.5 dB(A) at 2000 psi (14 MPa, 140 bar), 0.72 gpm (2.7 lpm)
Sound Power, per ISO
9614-2
88.6 dB(A) in fast circulation mode
94.4 dB(A) at 2000 psi (14 MPa, 140 bar), 0.72 gpm (2.7 lpm)
