Graco RS - Internal MIX Chop Gun, 258854

Component Identification
12 3A0232ZAA
Internal Mix Chop Gun, 258854
NOTE: On internal mix guns, the tip rotates to allow ver-
tical or horizontal spray pattern.
F
IG. 3
Key:
A Trigger Clamp Assembly
B Cutter Mount
C Front Head Locking Ring
D Air Cap Retaining Ring
E Internal Mix Aircap
F Internal Mix Front Head
G Spray Tip
H Trigger guard
J Trigger
K Trigger lock
L Handle
MActuator Pin
ti21004b
A
B
C
D
E
F
H
J
K
G
L
M
