Graco RS - Impingement Spray Tips

Accessories
58 3A0232ZAA
Impingement Spray Tips
*Available in tooling steel
Pattern Width Increases
6 in.
(15 cm)
8 in.
(20 cm)
10 in.
(25 cm)
12 in.
(30 cm)
14 in.
(36 cm)
16 in.
(41 cm)
18 in.
(46 cm)
Flow Increases
CSTS31 CSTS41 CSTS51 CSTS61 CSTS71 CSTS81 CSTS91
CSTS32 CSTS42 CSTS52 CSTS62 CSTS72 CSTS82 CSTS92
CSTS33 CSTS43 CSTS53 CSTS63 CSTS73 CSTS83
CSTS34 CSTS44 CSTS54 CSTS64 CSTS74 CSTS84
CSTS35 CSTS45 CSTS55 CSTS65 CSTS75 CSTS85
CSTS36* CSTS46* CSTS56* CSTS66* CSTS76* CSTS86*
CSTS37* CSTS47* CSTS57* CSTS67* CSTS77 CSTS87
CSTS58 CSTS68 CSTS78 CSTS88
RS Gun
Impingement Spray
Tip Part No. †
Angled Hole
Diameter
Straight Hole
Diameter Pattern Width 
GlasCraft
®
Tip
Part No. Ref
CSTS31 0.018 in. (0.46 mm) 0.012 in. (0.30 mm) 6 in. (150 mm) 23005-C1
CSTS32 0.021 (0.53) 0.014 (0.36) 6 (150) 23005-C2
CSTS33 0.036 (0.91) 0.025 (0.64) 6 (150) 23005-C3
CSTS34 0.042 (1.07) 0.029 (0.74) 6 (150) 23005-C4
CSTS35 0.052 (1.32) 0.036 (0.91) 6 (150) 23005-C5
CSTS36 0.062 (1.57) 0.043 (1.09) 6 (150) 23005-C6
CSTS37 0.070 (1.78) 0.052 (1.32) 6 (150) 23005-C7
CSTS41 0.018 (0.46) 0.012 (0.30) 8 (200) 23005-E1
CSTS42 0.021 (0.53) 0.014 (0.36) 8 (200) 23005-E2
CSTS43 0.036 (0.91) 0.025 (0.64) 8 (200) 23005-E3
CSTS44 0.042 (1.07) 0.029 (0.74) 8 (200) 23005-E4
CSTS45 0.052 (1.32) 0.036 (0.91) 8 (200) 23005-E5
CSTS46 0.062 (1.57) 0.043 (1.09) 8 (200) 23005-E6
CSTS47 0.070 (1.78) 0.052 (1.32) 8 (200) 23005-E7
CSTS51 0.018 (0.46) 0.012 (0.30) 10 (250) 23005-G1
CSTS52 0.021 (0.53) 0.014 (0.36) 10 (250) 23005-G2
CSTS53 0.036 (0.91) 0.025 (0.64) 10 (250) 23005-G3
CSTS54 0.042 (1.07) 0.029 (0.74) 10 (250) 23005-G4
CSTS55 0.052 (1.32) 0.036 (0.91) 10 (250) 23005-G5
CSTS56 0.062 (1.57) 0.043 (1.09) 10 (250) 23005-G6
CSTS57 0.070 (1.78) 0.052 (1.32) 10 (250) 23005-G7
CSTS58 0.081 (2.06) 0.055 (1.40) 10 (250) 23005-G8
