Accessories
3A0232ZAA 59
† Tip Code Reference:
CST = Composite Spray Tip
4th digit = S for stainless steel, T for tool steel
CSTS61 0.018 (0.46) 0.012 (0.30) 12 (300) 23005-J1
CSTS62 0.021 (0.53) 0.014 (0.36) 12 (300) 23005-J2
CSTS63 0.036 (0.91) 0.025 (0.64) 12 (300) 23005-J3
CSTS64 0.042 (1.07) 0.029 (0.74) 12 (300) 23005-J4
CSTS65 0.052 (1.32) 0.036 (0.91) 12 (300) 23005-J5
CSTS66 0.062 (1.57) 0.043 (1.09) 12 (300) 23005-J6
CSTS67 0.070 (1.78) 0.052 (1.32) 12 (300) 23005-J7
CSTS68 0.081 (2.06) 0.055 (1.40) 12 (300) 23005-J8
CSTS71 0.018 (0.46) 0.012 (0.30) 14 (350) 23005-K1
CSTS72 0.021 (0.53) 0.014 (0.36) 14 (350) 23005-K2
CSTS73 0.036 (0.91) 0.025 (0.64) 14 (350) 23005-K3
CSTS74 0.042 (1.07) 0.029 (0.74) 14 (350) 23005-K4
CSTS75 0.052 (1.32) 0.036 (0.91) 14 (350) 23005-K5
CSTS76 0.062 (1.57) 0.043 (1.09) 14 (350) 23005-K6
CSTS77 0.070 (1.78) 0.052 (1.32) 14 (350) 23005-K7
CSTS78 0.081 (2.06) 0.055 (1.40) 14 (350) 23005-K8
CSTS81 0.018 (0.46) 0.012 (0.30) 16 (400) 23005-M1
CSTS82 0.021 (0.53) 0.014 (0.36) 16 (400) 23005-M2
CSTS83 0.036 (0.91) 0.025 (0.64) 16 (400) 23005-M3
CSTS84 0.042 (1.07) 0.029 (0.74) 16 (400) 23005-M4
CSTS85 0.052 (1.32) 0.036 (0.91) 16 (400) 23005-M5
CSTS86 0.062 (1.57) 0.043 (1.09) 16 (400) 23005-M6
CSTS87 0.070 (1.78) 0.052 (1.32) 16 (400) 23005-M7
CSTS88 0.081 (2.06) 0.055 (1.40) 16 (400) 23005-M8
CSTS91 0.018 (0.46) 0.012 (0.30) 18 (450) 23005-P1
CSTS92 0.021 (0.53) 0.014 (0.36) 18 (450) 23005-P2
CSTT36 0.062 (1.57) 0.043 (1.09) 6 (150) 23005-TC6
CSTT37 0.070 (1.78) 0.052 (1.32) 6 (150) 23005-TC7
CSTT46 0.062 (1.57) 0.043 (1.09) 8 (200) 23005-TE6
CSTT47 0.070 (1.78) 0.052 (1.32) 8 (200) 23005-TE7
CSTT56 0.062 (1.57) 0.043 (1.09) 10 (250) 23005-TG6
CSTT57 0.070 (1.78) 0.052 (1.32) 10 (250) 23005-TG7
CSTT66 0.062 (1.57) 0.043 (1.09) 12 (300) 23005-TJ6
CSTT67 0.070 (1.78) 0.052 (1.32) 12 (300) 23005-TJ7
CSTT76 0.062 (1.57) 0.043 (1.09) 14 (350) 23005-TK6
CSTT86 0.062 (1.57) 0.043 (1.09) 16 (400) 23005-TM6
RS Gun
Impingement Spray
Tip Part No. †
Angled Hole
Diameter
Straight Hole
Diameter Pattern Width 
GlasCraft
®
Tip
Part No. Ref
