Parts
46 3A0232ZAA
External Mix, Internal Mix, and Internal Mix High Flow Chop Gun Parts
Ref Part Description
Quantity
258852 258854 24P436
500 199360 DOCUMENT, declaration 1 1 1
501 24N711 HANDLE, gun 1 1 1
502† 24E428 SEAL, needle, seat (pack of 6) 2 2 2
503 16C104‡ RETAINER, seat, needle valve, resin 1 1
24M833‡ RETAINER, seat, needle valve, resin, carbide
1
504 24D201 RETAINER, seat, catalyst
111
505** 24E417 NEEDLE, assembly 2 2 2
506  16C101 NEEDLE, aac 1 1 1
507 123633 SPRING, needle assembly 1 1 1
508 16C100 RETAINER, aac 1 1 1
509 24E429 O-RING (pack of 6) 1 1 1
510 24E430 O-RING (pack of 6) 1 1 1
511 16C098 CLAMP, trigger, top 1 1 1
512 16C099 CLAMP, trigger, bottom 1 1 1
513 124057 SCREW, cap, sh 4 4 4
514 GC2082 SCREW, set, flpt 2 2 2
515 24G764 HOUSING, check valve, catalyst 1 1
24E423 HOUSING, check valve, catalyst 1
515a 123934 O-RING, FKM (smaller o-ring in housing) 1 1 1
515b 112319 O-RING (larger o-rings on outside of housing) 2 2 2
516a 24E424 HOUSING 3 2 2
516a1 112319 O-RING 1 1 1
516b 24H270 HOUSING, check valve asm, solvent 1 1
516b1 123934 O-RING, FKM (smaller o-ring in housing) 1 1 1
516b2 112319 O-RING (larger o-rings on outside of housing) 2 2 2
517 24E426 HEAD, external mix, horizontal 1
24E442 HEAD, internal mix, chop 1
24P562 HEAD, internal mix, chop, high flow 1
517a 123934 O-RING, FKM (smaller o-ring in housing) 1 1 1
517b 112319 O-RING (larger o-rings on outside of housing) 2 2 2
518 24E425 VALVE, air, assy, trigger 1 1 1
520 179737 PIN, actuator 2 2 2
521 16C085 TRIGGER, gun, 2-finger 1 1 1
521a 16F627 TRIGGER, 4-finger (not shown) 1 1 1
522 123733 BOLT, shoulder, self locking 2 2 2
523 276745 STOP, trigger 1 1 1
524 112033 PIN, dowel 1 1 1
525 16C130 GUARD, trigger 1 1 1
526 111945 SCREW, cap, fl hd 2 2 2
527 16C107 FITTING, resin hose 1 1 1
528* 16C118 FITTING, solvent 1 1 1
529* 16C117 VALVE 1 1 1
530* 24E437 PACKING, o-ring (pack of 6) 1 1 1
531* 24E431 O-RING (pack of 6) 1 1 1
532* 24E432 RING, retaining, e-ring (pack of 6) 1 1 1
533* 16C119 FITTING, insert, solvent 1 1 1
534* 111450 PACKING, o-ring 2 2 2
535 123737 FITTING, tube, push connector 1 1 1
536 123736 FITTING, tube, push connector 1 1 1
537 16D039 RESTRICTOR, catalyst 1 1
