Graco Simulation XM Repair Parts

Electrical Schematics
3A2989V 39
AC Power Schematic Purge Box
CB1-1
CB1-3
CB2-1
CB2-3
CB3-1
CB3-3
CB4-1
CB4-3
CB5-1
CB5-3
TB16
TB15 TB14 TB13 TB12 TB11
Switch SW2
15U423
Tank Heater
Switch SW3 15U423
Flush Heater
Circuit Breaker DIN Rail 24X085
1
3
CB-A
CB-B
PS-N
PS-
L
TCM-1 Temperature Control 24Y169
Power Supply 126453
Surge Protector 16U530
2
4
1
3
2
4
Bushing 17B984 Input Power
To Explosion Proof Box
TB10
TB12
TB13 TB15
CT1-L1
CT1-L2
CT1-L3 CT1-L4
CB1-2
CB1-4
CB2-2
CB2-4
CB3-2
CB3-4
CB4-2
CB4-4
CB5-2
CB5-4
TCM-H2
T
CM-H1
TCM-B2
TCM-B1
TCM-A2
TCM-A1
TB8
TB9
TB6
TB7
SW3-2
SW3-4
SW2-2
SW2-4
SW2-1
SW2-3
SW3-3
SW3-1
TCM-GND
GND-2
Ground Bar 122313
Small Door Ground Wire 17D194
GND-2
GND-3
Jumper Key
200-240 VAC Delta Power
350-415 VAC Wye Power
PS1
SSP
FILTER 17F662
FILTER 17F662
FILTER 17F662
HTR-A-CB3-2
HTR-A-CB3-4
HTR-H-CB1-2
HTR-H-CB1-4
HTR-B-CB2-2
HTR-B-CB2-4
A
B
H
8 AWG Copper Wire
10 AWG Copper Wire
ti27662a
