Graco Simulation XM Repair Parts

Technical Data
82 3A2989V
Technical Data
XM PFP
US Metric
Ratio Tolerance Range (before alarm) +/- 5%
Maximum Flow Rate (measured with oil) 3 gallons per minute 13.6 liters per minute
Fluid Viscosity Range
Handles mastic materials which are loaded into heated tanks with
ram-fed priming piston pumps
Air Inlet 1 in. npt(f)
Fluid Inlets Pail (Pail Feed RAM Pumps)
Maximum Fluid Working Pressure for A and B
Materials
6000 psi 41 MPa, 414 bar
Maximum Fluid Working Pressure for Flushing
Fluid
4500 psi 31 MPa, 7 bar
Maximum Fluid Working Pressure for Heating
Fluid
100 psi 0.7 MPa, 7 bar
Maximum Fluid Temperature 160°F 70°C
System Inlet Supplied Air Pressure Range 80-150 psi 0.5-1.0 MPa, 5.5-10.3 bar
Maximum Pump Air Pressure 100 psi 0.7 MPa, 7 bar
Maximum Tank Air Pressure 90 psi 0.6 MPa, 6 bar
Air Filtration 40 micron main filter, 5 micron control air filter, 3 micron purge con
troller filter (Hazardous Location only)
Ambient Operating Temperature Range 32 to 130°F 0 to 54°C
Ambient Storage Temperature Range 30 to 160°F -1 to 71°C
Environmental Conditions Rating Altitude up to 13,123 ft Altitude up to 4000 m
Sound Pressure * 86 dBA at 100 psi 86 dBA at 0.7 MPa, 7 bar
Sound Power ** 98 dBA at 100 psi 98 dBA at 0.7 MPa, 7 bar
System Weight (empty, no fluid) 2175 lb 987 kg
Mix Ratio Range
262869, 262943 1.5:1 to 4:1
24W626, 262945 1:1 to 1.5:1
Air Consumption
Minimum 100 scfm
2.8 meter
3
/min
Maximum 250 scfm
7.1 meter
3
/min
Typical Application 125-175 scfm
3.5-5.0 meter
3
/min
Power Requirements
Voltage (can be set with jumpers) Option 1: 200-240 VAC, 3 phase DELTA (3 wire plus ground)
Option 2: 350-415 VAC, 3 phase WYE (4 wire including neutral plus
ground)
Wattage 18,800 watts (non-hazardous location)
18,900 watts (hazardous location)
22,900 watts (with hazardous location flush water heater)
23,400 watts (with optional non-hazardous location flush water
heater)
Amps 200-240 VAC, 3-phase models DELTA: 63 Amps per phase full load
350-415 VAC, 3-phase models WYE: 40 Amps per phase full load
