Graco Simulation XM User Manual

Models
3A2776K 3
Models
System Series Location
Ratio
Range
Approvals
24W626 B
Non-Hazardous
1:1 to
1.5:1
262869 B
1.5:1 to
4:1
262945 A
Hazardous
1:1 to
1.5:1
ATEX Ratings:
ATEX Certificate No. ITS15ATEX18241X
IECEx Ratings Ex db ia pxb IIA T3 Gb
IECEx Certificate No. IECEx ETL 15.0020X
Ta = 0°C to 54°C
See Technical Specifications, page 98, for additional information.
262943 A
1.5:1 to
4:1
9902471
Certified to CAN/CSA C22.2 No. 88
Conforms to
UL 499
Not for use in explosive atmospheres or hazardous
locations.
9902471
Certified to CAN/CSA C22.2 No. 88
Conforms to
UL 499
II 2 G Ex db ia pxb IIA T3 Gb
Maximum Fluid Working Pressure Maximum Air Working Pressure
A and B Materials:
6000 psi (41 MPa, 414 bar)
Flushing Fluid:
4500 psi (31 MPa, 310 bar)
Heating Fluid:
100 psi (0.7 MPa, 7 bar)
Supply:
150 psi (1.0 MPa, 10.3 bar)
Maximum Setpoint:
Main Pump: 100 psi (0.7 MPa, 7 bar)
Feed Pump: 65 psi (0.45 MPa, 4.5 bar)

Graco Simulation XM Specifications

General

Brand	Graco
Model	Simulation XM
Category	Paint Sprayer
Language	English
