Firmware version 1.0.0.31 DP715/DP710 User Manual Page 40 of 56
In addition to the Basic Settings configuration page, end users also have access to the Device Status page.
Table 12:STATUS PAGE
The device ID, in HEX format. This is very important ID for ISP troubleshooting. The Mac
address will appear in this place. The MAC address will be used for provisioning and can
be found on the label coming with original box and on the label located on the bottom
Radio Fixed Part Identity; indicate the unique identification number of the DP715 base
station.
This field shows the IP address of the DP715.
This field contains the product model info (“DP715”).
This field shows the hardware revision of the unit and the part number.
Program: This is the main software release. This number is always used for firmware
upgrade. Current release is 1.0.0.1 Boot and Loader are seldom changed.
Bootloader:current version is 1.0.0.1.
Core: current version 1.0.0.0
Base: current version is 1.0.0.0
Running Mem: 3980, indicate if the software is running and display the memory usage.
Shows system up time since the last reboot.
Indicates whether the PPPoE connection is up if the DP715 is connected to DSL modem.
This filed indicates the type of NAT connection used by the DP715.
Displays relevant information regarding the Handset subscription status.
• Handset 1 is subscribed with the DP715 base station.
• IPUI (“International Portable User Identity
“): is the identifier of each Handset registered
to the base.
• TPUI (“Temporary Portable User Identity
”): Allocated to the Handset automatically by
the DP715 base.
Displays relevant information regarding the Handset status.
• Handset 1 is registered with SIP Server.
• Handset 1 user has set Do Not Disturb.
• Handset 1 user has set his calls to be unconditionally forwarded to ext 613.
• Handset 1 user has not set Busy or Delay call Forward.
