GXP21XX Administration Guide
 Network: To configure network settings.
 Maintenance: To configure web access, upgrading and provisioning, syslog, language settings, TR-
069, security and etc.
 Phonebook: To manage Phonebook and LDAP.
Status Page Definitions
Table 9: Status Page Definitions
Status  Account Status
Account
Account index.
For GXP2130: up to 3 SIP accounts
For GXP2140: up to 4 SIP accounts
For GXP2160: up to 6 SIP accounts
For GXP2170: up to 6 SIP accounts
For GXP2135: up to 4 SIP accounts
SIP User ID
Displays the configured SIP User ID for the account.
SIP Server
Displays the configured SIP Server address, URL or IP address, and port of
the SIP server.
SIP Registration
Displays SIP registration status for the SIP account, it will display Yes/No
with Green/Red background.
Status  Network Status
MAC Address
Global unique ID of device, in HEX format. The MAC address will be used
for provisioning and can be found on the label coming with original box and
on the label located on the back of the device.
IP Setting
The configured address type: DHCP, Static IP or PPPoE.
IPv4 Address
The IPv4 address obtained on the phone.
IPv6 Address
The IPv6 address obtained on the phone.
OpenVPN IP
The OpenVPN IP obtained on the phone.
Subnet Mask
The subnet mask obtained on the phone.
Gateway
The gateway address obtained on the phone.
DNS Server 1
The DNS server address 1 obtained on the phone.
DNS Server 2
The DNS server address 2 obtained on the phone.
PPPoE Link Up
PPPoE connection status.
NAT Type
The type of NAT connection used by the phone.
NAT Traversal
Display the status of NAT connection for each account on the phone.
Status  System Info
Product Model
Product model of the phone.
Part Number
Product part number.
Software Version
 Boot: boot version number;
 Core: core version number;
