For example:
If users set MPK 1 as “LDAP Search” for “Account 1”, and set filters:
Description -> ou=video,ou=SZ,dc=grandstream,dc=com
Value -> sn=Li
Since the Base for LDAP server configuration is
“dc=65randstream,dc=com”, “ou=video,ou=SZ” is added to narrow the
LDAP search scope. “sn=Li” is the example to filter the last name.
Call Log
Select Account and enter account number in the Value field to access to
the Call Log of that selected account.
Menu
Select this feature in order to display the Menu from the MPK buttons,
no field dis required for configuration.
Information
Select this feature in order to display the Information popup to show the
firmware version, MAC address, IP address and IP Settings from the
MPK buttons, no field dis required for configuration.
Message
Select this feature in order to display the Message menu from the MPK
buttons, no field dis required for configuration
One Page Display Mode
Each extension board only shows 20 Extensions, that is, EXT 1 ~ 80 could
be displayed on 4 connected boards if the mode is enabled.
Sync Backlight with LCD
If set to yes, the Extension Board backlight will turn off when LCD is idle.
Assigns a function to the corresponding Extension Board key.
The key mode options are:
None
Select this option in order to disable the key.
Speed Dial
Select the Account to dial from. And enter the Speed Dial number in the
Value field to be dialed, or enter the IP address to set the Direct IP call
as Speed Dial.
Busy Lamp Field (BLF)
Select the Account to monitor the BLF status. Enter the extension
number in the Value field to be monitored.
Presence Watcher
This option has to be supported by a presence server and it is tied to the
“Do Not Disturb” status of the phone’s extension.
Eventlist BLF
This option is similar to the BLF option but in this case the PBX collects
To Next Page
