Grandstream Networks GXV3275 Administration Guide

Firmware Version 1.0.3.46
GXV3275 Administration Guide
Page 89 of 117
View Trace
It is enter the phone system’s directory to view the captured trace files
from the web browser. In the directory, click on the name of the file to
download it.
Note: The trace files are saved in phone’s internal storage. Users can
access or delete the trace files from LCD->FileManager->Internal
Storage->ppp directory.
MAINTENANCE/LANGUAGE
Language
It is used to set the language to display on the phone's LCD.
MAINTENANCE/EVENT NOTIFY
Set the URL for events on phone web GUI, and when the corresponding event occurs on the phone, the
phone will send the configured URL to SIP server. The dynamic variables in the URL will be replaced by
the actual values of the phone before sending to SIP server, in order to achieve the purpose of events
notification. Here are the standards:
1. The IP address of the SIP server needs to be added at the beginning, and separate the dynamic
variables with a "/".
2. The dynamic variables need to have a "$" at the beginning.
For example: local=$local
3. If users need to add multiple dynamic variables in the same event, users could use "&" to connect with
different dynamic variables.
For example: 192.168.40.207/mac=$mac&local=$local
4. When the corresponding event occurs on the phone, the phone will send the MAC address and phone
number to server address 192.168.40.207.
On Boot Completed
This is used to configure the event URL when phone boots up.
Incoming Call
This is used to configure the event URL when phone has an incoming
call.
Outgoing Call
This is used to configure the event URL when phone has an outgoing
call.
On Offhook
This is used to configure the event URL when the phone is offhook.
