2. Enter the multicast paging description in Display Name field.
3. Enter multicast paging address and port in URL field. The range of multicast page address is 224.0.0.0 to 239.255.255.255
with a port not in use by phone.
To receive multicast page, the GXV34x0 must be well configured to listen to the right address and port. The configurations are
under Phone Settings->Multicast Paging
🡪 Multicast Listening. There are 10 listening address supported. After multicast
page listening well configured, please reboot the phone to let the settings take effect.
Multicast Listening switch
Users can enable/Disable multicast listening feature from Multicast listening widget. When Multicast Listening Widget is set to
ON; The phone will be listening to Multicast paging calls.
Figure 90: Multicast Paging ON
Missed Call
When there is a missed call, the LCD will show missed call dialog on the idle screen.
