FIRMWARE VERSION 1.0.9.1 GXW40XX USER MANUAL Page 41 of 60
Syslog Level
Select the GXW40XX to report the log level. Default is NONE. The level is one of
DEBUG, INFO, WARNING or ERROR. Syslog messages are sent based on the
following events:
1. product model/version on boot up (INFO level)
2. NAT related info (INFO level)
3. sent or received SIP message (DEBUG level)
4. SIP message summary (INFO level)
5. inbound and outbound calls (INFO level)
6. registration status change (INFO level)
7. negotiated codec (INFO level)
8. Ethernet link up (INFO level)
9. SLIC chip exception (WARNING and ERROR levels)
10. memory exception (ERROR level)
The Syslog uses USER facility. In addition to standard Syslog payload, it contains
the following components:
GS_LOG: [device MAC address][error code] error message
Example: May 19 02:40:38 192.168.1.14 GS_LOG: [00:0b:82:00:a1:be][000]
Ethernet link is up
Send SIP Log
If Syslog is enabled and Send SIP Log is set to YES, then SIP messages will also be
delivered via Syslog. Default is set to NO.
Primary RADIUS Server
IP Address or FQDN of the primary RADIUS Server
Primary RADIUS Auth Port
Primary Radius server authentication port. Default value is 1812
Primary RADIUS Acct Port
Primary Radius server accounting port. Default value is 1813
Primary Radius Server
Secret
Special secret string should be preconfigured according to RADIUS Server
configuration
Secondary RADIUS Server
IP Address or FQDN of the secondary RADIUS Server
Secondary RADIUS Auth
Port
Secondary Radius server authentication port. Default value is 1812
Secondary RADIUS Acct
Port
Secondary Radius server accounting port. Default value is 1813
Secondary Radius Server
Secret
Special secret string should be preconfigured according to RADIUS Server
configuration
