Grandstream Networks HT701 User Manual

P a g e | 13
HT70X User manual
Version 1.0.9.4
Table 2: Basic Definitions of the HT70X LEDs Pattern
POWER LED
Indicates Power. Remains ON when power is connected
Internet LED
Indicates Access to Internet. Remains ON while there is Access (HT701 and
HT702 Only)
Link/Activity
LED
Indicates if There is Activity on the Internet Port (HT701 and HT702 Only)
PHONE LED
Indicate status of the respective FXS Ports-PHONE on the back panel:
Unregistered – OFF
Registered and Available – ON (Solid Green)
Off-Hook / Busy – Blinking every second
Slow blinking FXS LEDs indicates voicemail
NOTE: All LEDs display green when ON
Table 3: Advanced Definitions of the HT70X LEDs Pattern
LED-01
Device has normal power
Power
ON
LED-02
Power Error: Power is removed from the device or
power supply with improper voltage is plugged in
Power
OFF
LED-03
Line X is registered normally to the sip providers
network and is ready to make a call
Phone
ON
LED-04
Voice mail waiting for Line X
Phone
1sec ON / 3sec OFF
LED-05
Device has normal WAN connection and has obtained
IP address
Internet
ON
LED-06
Internet link error: Device is powered up and ready to
connect to the Internet but the WAN/INTERNET port
is down
Internet
OFF
LED-07
Internet DHCP Error: Device is properly connected
but it is unable to retrieve an IP address from the
device it is connected
Internet
250ms ON/ 250ms
OFF
LED-08
Line Registration failed: Device is properly setup,
can connect to provider's network, but cannot register
to provider's SIP proxy (no 200 OK)
Phone
2x1000ms ON/OFF
+
3sec OFF

Grandstream Networks HT701 Specifications

General

Brand	Grandstream Networks
Model	HT701
Category	Adapter
Language	English
