HT70X User manual
Version 1.0.9.4
Download Device
Configuration
Allows user to download and save a text file containing all the P values of each
setting as configured at that point on the unit. For Security Reasons, Passwords
won’t be Downloaded
Allows the user to upgrade the firmware with a single firmware file by browsing
and loading the file from your computer (local directory)
Table 11: Account Settings
When set to Yes the FXS port or Profile (for HT704) is activated.
SIP Server’s IP address or Domain name provided by VoIP service provider.
Failover SIP Server’s IP address or Domain name in case primary server does
not respond.
Prefer Primary SIP
Server
Default is No. If set to yes, it will register to Primary Server if registration with
Failover server expires
IP address or Domain name of Outbound Proxy, or Media Gateway, or Session
Border Controller. Used by HT70X for firewall or NAT penetration in different
network environments. If symmetric NAT is detected, STUN will not work and
ONLY outbound proxy can correct the problem.
Allow DHCP Option
120(override SIP
server)
Default is No. If set to Yes, device will collect SIP server address from DHCP
option 120 for FXS1 (HT701/2) or Profile1 (HT704).
User can select UDP or TCP or TLS. Default is UDP.
User account information, provided by VoIP service provider (ITSP). Usually in
the form of digit similar to phone number or actually a phone number. HT701
and HT702 only
SIP service subscriber’s Authenticate ID used for authentication. Can be
identical to or different from SIP User ID. HT701 and HT702 only
SIP service subscriber’s account password. HT701 and HT702 only
SIP service subscriber’s name for Caller ID display. HT701 and HT702 only
To Next Page
