HT70X User manual
Version 1.0.9.4
web user interface.
1. Access your HT701/HT702 web UI by entering its IP address in your favorite browser.
2. Enter your admin password (default: admin) and press Login to access your settings.
3. Go to FXS Port (1 or 2) pages.
4. In FXS Port tab, set the following:
a. Account Active to Yes.
b. Primary SIP Server field with your SIP server IP address or FQDN.
c. Failover SIP Server with your Failover SIP Server IP address or FQDN. Leave empty if not
available.
d. Prefer Primary SIP Server to No or Yes depending on your configuration. Set to No if no Failover
SIP Server is defined. If “Yes”, account will register to Primary SIP Server when failover
registration expires.
e. Outbound Proxy: Set your Outbound Proxy IP Address or FQDN. Leave empty if not available.
f. SIP User ID: User account information, provided by VoIP service provider (ITSP). Usually
in the form of digit like phone number or a phone number.
g. Authenticate ID: SIP service subscriber’s Authenticate ID used for authentication. Can be
identical to or different from SIP User ID.
h. Authenticate Password: SIP service subscriber’s account password to register to SIP
server of ITSP. For security reasons, the password will field will be shown as empty.
i. Name: Any name to identify this specific user.
5. Press Apply at the bottom of the page to save your configuration.
