DHCP MODE
Select voice menu option 01 to allow the HT812 to use DHCP.
STATIC IP MODE
Select voice menu option 01 to allow the HT812/HT814 to enable the STATIC IP mode, then use option
02, 03, 04, 05 to set up IP address, Subnet Mask, Gateway and DNS server respectively.
PPPOE MODE
Select voice menu option 01 to allow the HT812 to enable the PPPoE mode. PPPoE Username and
Password should be configured from web GUI.
FIRMWARE SERVER IP ADDRESS
Select voice menu option 13 to configure the IP address of the firmware server.
CONFIGURATION SERVER IP ADDRESS
Select voice menu option 14 to configure the IP address of the configuration server.
UPGRADE PROTOCOL
Select the menu option 15 to choose firmware and configuration upgrade protocol between TFTP / HTTP.
FIRMWARE UPGRADE MODE
Select voice menu option 17 to choose firmware upgrade mode among the following three options:
“Always check, check when pre/suffix changes, and never upgrade”.
WAN PORT WEB ACCESS
Select voice menu option 12 to enable/disable web access from WAN port. Press 9 in this menu to toggle
between enable / disable.
Register a SIP Account
The HT812 support 2 profiles which can be configured with 2 SIP accounts. Please refer to the following
steps in order to register your accounts via web user interface
1. Access your HT812 web UI by entering its IP address in your favorite browser.
2. Enter your admin password (default: admin).
3. Press Login to access your settings.
4. Go to Profile (1 or 2) pages.
5. In Profile tab, set the following:
a. Account Active to Yes.
b. Primary SIP Server field with your SIP server IP address or FQDN.
c. Failover SIP Server with your Failover SIP Server IP address or FQDN. Leave empty if not
available.
