UCM6XXX Analog Trunks Guide
Figure 31: Create New SLA Station
• Click on “Add” to add an SLA Station.
• Click on to edit the SLA Station. The following table shows the SLA Station configuration parameters.
• Click on to delete the SLA Station.
Table 2: SLA Station Configuration Parameters
Configure a name to identify the SLA Station.
Specify a SIP extension as a station that will be using SLA.
Existing Analog Trunks with SLA Mode enabled will be listed here.
Select a trunk for this SLA from the Available SLA Trunks list. Click on
to arrange the order. If there are multiple trunks selected, when there are calls on
those trunks at the same time, pressing the LINE key on the phone will pick up the
call on the first trunk here.
Configure the time (in seconds) to ring the station before the call is considered
unanswered. No timeout is set by default. If set to 0, there will be no timeout.
Configure the time (in seconds) for delay before ringing the station when a call first
coming in on the shared line. No delay is set by default. If set to 0, there will be no
delay.
This option defines the competence of the hold action for one particular trunk. If
set to “open”, any station could hold a call on that trunk or resume one held
session; if set to “private”, only the station that places the trunk call on hold could
resume the session. The default setting is “open”.
