Einbau und Anschlüsse
Helikoptermodelle
EMPFÄNGER
AKKU
WARNUNG
Antenne nicht kürzen!
ANTENNE
GYRO
GYRO
SCHALTERKABEL
Gasservo
Rollservo bzw.
Roll/Pitch (rechts)
Nickservo bzw.
Nick/Pitch (hinten)
Fahrwerkskanal-
Servo
Heckrotorservo
Roll/Pitch (links)
AUX1
GEAR
RUDD
ELEV
AILE
THRO
LADEBUCHSE
Einbau und Anschlüsse HELIKOPTERMODELLE
13
