102
Detail program description - Control adjust
To confi gure asymmetric travel, move the affected
transmitter control (proportional rotary control or switch)
to the side on which you wish to confi gure it, so the
marker frame encloses only the value you want to adjust:
–travel+
+100%
+100%
+100%
+100%
+100%
+100%
+100%
+100%
Normal
Input 5
Throt
Gyro
Input 8
6
7
Briefl y tap the center SET key on the right touch pad
to activate value confi guration: The value fi eld is shown
highlighted. Use the arrow keys on the right touch pad to
change the values:
–travel+
+100%
+100%
+100%
+100%
+100%
+100%
+111%+111%
Normal
Input 5
Throt
Gyro
Input 8
6
7
–travel+
+100%
+100%
+100%
+100%
+100%
+100%
+88%+111%
Normal
Input 5
Throt
Gyro
Input 8
6
7
Complete the confi guration by tapping the center SET
key on the right touch pad.
Negative and positive parameter values are possible in
order to appropriately adapt the control's direction or
effect.
If you tap the or keys on the right touch pad
(CLEAR) at the same time, this will reset parameters
changed in the highlighted fi eld back to +100%.
Important:
In contrast to altering servo travel, changing the control
travel setting affects all "downstream" mixer and
coupling inputs, i. e. any and all servos that could be
actuated by the transmitter controls concerned.
Column 6, "– time +"
Each of the function inputs 5 … 12 can be assigned a
symmetrical or asymmetric time delay of between 0 and
9.9. s.
Using the arrow key on the left or right touch pad,
move the marker frame over the "– travel +" column and
to the right.
To confi gure a symmetrical time delay, i. e. one
independent of the control side, move the affected
transmitter control (proportional rotary control or switch)
as necessary to a position at which the marker frame
encloses both sides of the time adjustment region:
– time +
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
Normal
Input 5
Throt
Gyro
Input 8
6
7
To confi gure an asymmetric time delay, move the
affected transmitter control (proportional rotary control
or switch) as required to the side on which you wish
to confi gure it, so the marker frame encloses only the
value you want to adjust:
– time +
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
Normal
Input 5
Throt
Gyro
Input 8
6
7
Note:
Other suggestions for designing timed sequences
can be found under "Controlling timed sequences" on
page 266.
