12
Introduction - Remote control set
24 model memories with storage for all model-•
specifi c programs and parameter settings
7 switches (2 three stage switches, 3 two stage •
switches and 2 touch switches) and 3 digital
actuators are already built-in and can be used as
desired
Free assignment of switches to switched functions by •
simply switching the desired switch
Simple programming of motor and brake switchover •
for electric gliders on the K1 joystick.
Internal realtime clock for time-stamping log fi les•
User-replaceable CR2032 buffer battery for the •
internal realtime clock
Model memory storage in a modern, non-volatile •
backup system
12 control functions with simplifi ed arrangement •
of operating elements for supplementary functions
like switches and proportional transducers make
operating convenient
Convenience mode selector for simplifi ed switchover •
between MODES 1 … 4 (Gas left/right, etc.)
All affected settings are also automatically switched
over.
Graphic servo position display for fast, simple •
overview and for checking servo movements
Transmitter output swapping•
Extensive programs for winged aircraft and helicopter •
models:
Winged aircraft menu for: 1 QR, 2 QR, 2 QR + 1, 2
and 4 WK as well as 4 QR + 2 and 4 WK, V tail unit,
delta/all-wing, 2 elevator servos
Surface mix: QR-diff, WK-diff, QR SR, QR
WK, brake HR, brake WK, brake QR, HR
WK, HR QR, WK HR, WK QR and diff.
reduction
Heli menu for: 1-, 2-, 3- and 4-point linkage (1 Sv,
2 Sv, 3 Sv (2 roll), 3 Sv (140°), 3 Sv (2 nick), 4 Sv
(90°))
16 free mixers, • 8 linear mixers, 4 curve mixers and 4
cross mixers
Swashplate limiter•
±150 % servo adjustment for all servo outputs, •
independently adjustable per side (Single Side Servo
Throw)
Sub-trim in the ±125 % range for setting all neutral •
servo positions
Servo reverse can be programmed for all servos •
Two stage DUAL RATE/EXPO system, individually •
adjustable for specifi c fl ight phase and switchable
during fl ight
Stop watches/countdown timers with alarm function•
Copy function for model memory•
Built-in DSC jack for connecting fl ight simulators or a •
teacher/pupil system
Envisioned for a later update:•
Voith-Schneider limiter, works similar to a swashplate
limiter
Door sequencer, e. g. for putting down landing gear
automatically or retractable powerplant with runout
controller
Nautical program
General HoTT features
Maximum noise immunity due to optimized frequency •
hopping and wider channel spread
Intelligent data transfer with correction function•
Computer System mx-20
12 channel remote control set with 2.4 GHz Graupner HoTT technology (Hopping Telemetry Transmission)
Realtime telemetry evaluation•
Over 200 systems can be used simultaneously•
Update capability via USB interface guarantees •
future viability
Simple, very fast transmitter to receiver binding•
Binding with multiple receivers per model • in parallel
operation is possible
Extremely fast rebinding, even at maximum distance•
Range test and warning function•
Receiver under-voltage warning in the transmitter's •
display
Extremely wide receiver operating voltage range of •
3.6 V to 8.4 V (fully functional to 2.5 V)
Failsafe•
Arbitrary channel assignment (channel mapping), mix •
functions and all servo settings can be programmed
in the telemetry menu
Up to 4 servos can be controlled simultaneously as •
a block at a servo cycle time of 10 ms (digital servos
only)
