15
Operating notices
Battery operation timer at the bottom left of the
screen
This timer shows the transmitter's cumulative operating
time since the transmitter's battery was last charged.
This timer is automatically reset to "0:00" when the
transmitter is switched on and its battery voltage is
signifi cantly higher than when the transmitter was last
used, e. g. because the battery was charged.
GRAUBELE
#01
0:00h
Stop
Flt
«normal »
K78
0:00
0:00
0.0V
5.9V
Mx
HoTT
Lithium battery, CR 2032
At the left side of the transmitter board there is a fi xture
for a lithium battery. The user can replace this battery
when necessary with another lithium battery of type
CR 2032:
This battery maintains the date and time settings during
a transmitter power supply outage, for example when
the transmitter's main battery is being replaced.
