Detail program description - Control adjust
Important notices:
Check that the model aircraft is operational •
and check that all functions issue the correct
commands BEFORE setting up trainer mode.
The ends of the trainer lead, usually marked as •
either "S" or "M", terminate in a three-pole TRS
jack. Do not insert these jacks into a DSC system
socket, as it is not suitable for this application.
The DSC socket is exclusively designed for a
trainer lead with 2-pole TRS jacks.
Checking functionality
Activate the assigned trainer mode switch:
The trainer mode system is working properly if the •
display now changes from "Teach" to "Pupil".
If the center LED rapidly fl ashes blue/red, however, •
and the unit beeps at the same time, then the pupil-
teacher transmitter connection has been lost.
The basic display also displays the following warning
notice …
No
pupil
signal
… and the left side of the screen display on the
"Teacher/pupil" menu changes to show "-Pupil".
In this case, all control functions are retained by
the teacher transmitter automatically, regardless of
switch position: this ensures the model is always
under control.
Possible faults:
Pupil transmitter not ready•
Interface in pupil transmitter not correctly connected •
in place of the RF module
Cables connected wrongly: see right for cable •
connections
Pupil transmitter not switched over to PPM (10, 18, •
24) mode
Other possible faults:
Teacher transmitter not properly "bound" to HoTT •
receiver in training model
Trainer leads
4179.1 For trainer mode operation between any two
Graupner transmitters equipped with a DSC
socket (identifi able by the two-pole TRS
jacks at each end of the lead)
3290.7 Trainer lead for connecting a teacher
transmitter with DSC socket (e. g. mx-20
HoTT) or a transmitter retrofi tted with the
optional DSC module, order no. 3290.24)
) to a Graupner pupil transmitter with an
optoelectronic pupil socket (identifi able by
the label "S" on the end with the three-pole
TRS jack).
3290.8 Trainer lead for connecting a pupil
transmitter with DSC socket (e. g. mx-20
HoTT) or a transmitter retrofi tted with the
optional DSC module, order no. 3290.24)
to a Graupner teacher transmitter with an
optoelectronic teacher socket (identifi able by
the label "M" on the end with the three-pole
TRS jack).
For further details about the cables and modules for
teacher and pupil transmitters mentioned in this section,
please consult the respective transmitter handbook,
the Graupner RC main catalog or the www.graupner.de
website.
