Transmitter description - Telemetry data display
SENSOR 2 (GENERAL + ELECTRIC modules)
0.0V
0°C
SENSOR 2
If attached, this display depicts currently measured
voltage and temperature from a "T(EMP)2" temperature/
voltage sensor, Order No. 33612 or 33613 for General-
Engine (Order No. 33610), General-Air (Order No. 33611)
or Electric-Air module (Order No. 33620).
Rotary speed sensor
U/min
0
0
0
If attached, this display depicts the speed measured
by a speed sensor, Order No. 33615 or 33616, for a
General-Engine (Order No. 33610), General-Air (Order
No. 33611) or Electric-Air module (Order No. 33620).
Notice:
The appropriate blade count must fi rst be set in the
module's telemetry menu before the correct speed can
be displayed.
Vario
0.0
0
m
m
s
If attached, this display will depict altitude relative to
location or starting location (in m) as well as the current
ascent/decent rate (in m/s) from data provided by a
GPS-/Vario module (Order No. 33600) or Vario module
(Order No. 33601) connected to the receiver's telemetry
connection.
GPS
N
W
E
S
Kmh
0
km/h
DIS
m
m/s
ALT
m
0
0
0.0
0
If attached to the receiver, this display will depict the
data from a GPS module with integrated Vario, Order
No. 33600.
The displayed items are as follows:
Value Explanation
km/h Speed
DIS horizontal distance in m
m/s ascent/decent rate in m/s
ALT altitude relative to starting location in m
GPS
N
RXSQ 0
DIS 0m
ALT 0m
0.0m/1s
0m/3s
0m/10s
N 0°00.0000
E 0°00.0000
W
E
S
Kmh
0
If attached to the receiver, this display will depict the
data from a GPS module with integrated Vario, Order
No. 33600.
Aside from the model's current position and speed, the
center section of this screen will also display current
altitude with respect to the starting location as well as
the model's current ascent/decent rate in m/1 s, m/3 s
and m/10 s, current reception quality and the model's
distance from its starting location.
The displayed items are as follows:
Value Explanation
W / N / E / S west / north / east / south
Kmh speed
RXSQ return channel signal strength
DIS distance
ALT current altitude with respect to starting
m/1 s m/1 s ascent/decent rate
m/3 s m/3 s ascent/decent rate
m/10 s m/10 s ascent/decent rate
