Detail program description - Control adjust
covers travel to both sides of the marked frame.
Input 5
–travel+
+100%
+100%
+100%
+100%
Input 6
Input 7
Input 8
+100%
+100%
+100%
+100%
Normal
To set asymmetric travel, the respective control
(proportional rotary control or switch) is to be moved to
the side on which the marked frame only includes the
value to be changed.
Input 5
–travel+
+100%
+100%
+100%
+100%
Input 6
Input 7
Input 8
+100%
+100%
+100%
+100%
Normal
The value setting is activated by briefl y pressing the
center SET button in the right touch pad. The value
fi eld will be displayed in inverse video. Values can be
changed with the arrow keys of the right touch pad.
Input 5
–travel+
+100%
+100%
+100%
Input 6
Input 7
Input 8
+100%
+100%
+100%
+111%+111%
Normal
Input 5
–travel+
+100%
+100%
+100%
Input 6
Input 7
Input 8
+100%
+100%
+100%
+88%+111%
Normal
Another brief press of the center SET button in the right
touch pad will complete the entry.
Negative and positive parameter values are possible in
order to appropriately adapt the control's direction or
effect.
Simultaneously pressing the or keys in
the right touch pad (CLEAR) will reset the changes
parameter in the inverse video entry fi eld back to
+100 %.
Important:
In contrast to the servo travel setting, control travel
setting effects all derived mixer and coupling functions,
i. e. infl uences all servos which can be actuated by way
of the respective control.
Column 6 "time"
A symmetric or asymmetric time delay between 0 and
9.9 s can be applied to each of the 5 ... 12 function
inputs.
Use the arrow keys in the left or right touch pad to
push the marker frame to the right, beyond the "-travel+"
column.
To set a symmetric, (i. e. control-side independent) time
delay, the respective operating element (proportional
rotary control or switch) must be put into a position
which covers time to both sides of the marked frame.
Input 5
– time +
0.0
0.0
0.0
0.0
Input 6
Input 7
Input 8
0.0
0.0
0.0
0.0
Normal
To set an asymmetric time delay, the respective control
(proportional rotary control or switch) is to be moved to
the side on which the marked frame only includes the
value to be changed.
Input 5
– time +
0.0
0.0
0.0
0.0
Input 6
Input 7
Input 8
0.0
0.0
0.0
0.0
Normal
Notice:
Further suggestions for structuring timed fl ows can be
found in the section "Control of timed fl ows" on page 266.
