Loosen the screws on the mounting plate
and take it out.
Loosen the screws on the baffle of the
pipe outlet, and then press it downward
to pull out the buckles on both side, after
that, take the baffle away.
Loosen the screws and clamps on the
connection board of the evaporator,
disconnect the earth lead, and then take
the power cord of the motor, electric
heater and earth lead out through the
wire-cross hole, after that loosen the
screws on the fixed mount and remove it
away, finally take the evaporator out
upward.
Loosen the screws on the retaining plate
and the screw bolts on the motor, after
that, take the motor out.
Loosen four screws fixing the water
pump, disconnect the water pipe of the
pump, take the mounting bracket away,
then loosen these two screws fixing the
water pipe, after that, take the water pipe
away.
