Unit MAIN
TENANCE
58
④
Dis
assemble the
electrical box
Loosen two screws on the cover of the
electric box and then remove it aw
ay.
Disconnect the wiring terminals of the motor
and the temperature sensing bulb, then
loosen two screws fixing the electric box
,
after that, remove the electric box
away.
⑤
Dis
assemble the
baffle at the pipe
outlet.
Loosen two screws on the baffle and take it
out by turning it upward.
⑥
Dis
assemble the
water pump
Loosen the screws fixing the drain pan and
then take the it out upward.
59
