GREE GMV5 INDOOR UNIT SERVICE MANUAL
198
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-ND56PLS/A-T
CM800N3510
GMV-ND63PLS/A-T
CM800N3430
Part code
Quantity
Part code
Quantity
16
Electric Box Cover
01424100035
1
01424100035
1
17
Sealplate sub-assy (drainage)
01495315
1
01495315
1
18
Sealplate sub-assy (outlet)
01495316
1
01495316
1
19
Left Side Plate Assy
01315200087
1
01315200087
1
20
Water Level Switch
45020216
1
45020216
1
21
Water Pump
43138000068
1
43138000068
1
22
Strainer
0741410000601
2
0741410000601
2
23
Electronic Expansion Valve
07334466
1
07334466
1
24
Evaporator Assy
01024100111
1
01024100111
1
25
Cover of Air Outlet
01265335
1
01265335
1
26
Air Outlet Frame Assy
01374635
1
01374635
1
27
Water Tray Assy
01285334
1
01285334
1
28
Supporter
01895225
2
01895225
2
29
Top Cover Board Assy
01265339
1
1265339
1
30
Choke Plug of Drain Pipe
76815214
2
76815214
2
31
Right Side Plate Assy
01305263
1
01305263
1
32
Display Board
30296000040
1
30296000040
1
33
Sensor Sub-assy
39004168G
1
9004168G
1
34
Drain Hose Sub-Assy
05232050
1
05232050
1
35
Pump Drainpipe
200070000008
1
200070000008
1
36
Corrugated Pipe
05015408
1
05015408
1
37
Electric Expand Valve Fitting
4304413215
1
4304413215
1
Above data is subject to change without notice, pls reference the SP in global service website.
