GREE GMV5E DC INVERTER VRF UNITS SERVICE MANUAL
94
Note:
Un indicates the entire-unit bar code and Pc indicates the controller bar code.
After confirming the module, select a bar code sequence by pressing "SW1 (▲)" or "SW2 (▼)". The
display sequence is as follows:
Entire-unit bar code (bits 1-13) and controller bar code (bits 1-13), that is, entire-unit bar code
header → entire-unit bar code (bits 1-6) → entire-unit bar code (bits 7-12) → entire-unit bar code (bit 13)
→ controller bar code header → controller bar code (bits 1-6) → controller bar code (bits 7-12) →
controller bar code (bit 13). The display is as follows:
LED1
LED2
LED3
Parameter Code
Display Mode
Parameter Code
Display Mode
Parameter Code
Display Mode
Code
On
Code
On
Code
On
Example:
Entire-unit bar code: N1R0128150066
Controller bar code: N1M0128150067
The display sequence is as follows:
LED1
LED2
LED3
Parameter Code
Display Mode
Parameter Code
Display Mode
Parameter Code
Display Mode
nb
On
Un
Blinking
-n
Blinking
↓
LED1
LED2
LED3
Parameter Code
Display Mode
Parameter Code
Display Mode
Parameter Code
Display Mode
N1
On
R0
On
12
On
↓
LED1
LED2
LED3
Parameter Code
Display Mode
Parameter Code
Display Mode
Parameter Code
Display Mode
81
On
50
On
06
On
↓
LED1
LED2
LED3
Parameter Code
Display Mode
Parameter Code
Display Mode
Parameter Code
Display Mode
6X
On/Off
XX
Off
XX
Off
LED1
LED2
LED3
Parameter Code
Display Mode
Parameter Code
Display Mode
Parameter Code
Display Mode
nb
On
Pc
Blinking
-n
Blinking
↓
LED1
LED2
LED3
Parameter Code
Display Mode
Parameter Code
Display Mode
Parameter Code
Display Mode
N1
On
M0
On
12
On
LED1
LED2
LED3
Parameter Code
Display Mode
Parameter Code
Display Mode
Parameter Code
Display Mode
81
On
50
On
06
On
↓
LED1
LED2
LED3
Parameter Code
Display Mode
Parameter Code
Display Mode
Parameter Code
Display Mode
7X
On/Off
XX
Off
XX
Off
If a parameter is invalid for the unit, "00" is displayed.
On the master unit, press "SW6" to return to the upper level if there are two levels of menu. Press
